NiMH AAA 1.2V 1000MAH

NiMH Rechargeable Cell:  AAA 1.2V 1000mAh battery. The best safety and environmental friendly.


Parameters

Cell Model NiMH AAA
Voltage
  • Nominal Voltage: 1.2V
  • Charge Voltage: 1.5V±0.05V
  • Discharge Cut off Voltage: 1.0V
Capacity (0.2C Discharge)
  • Nominal Capacity: 1050 mAh
  • Minimum Capacity: 1000mAh
Standard Charge (25°C±2°C)
  • CC/CV
    • Current: 0.2C (200mA)
    • Voltage: 1.50V
    • End of current: 30mA
Charge Current
  • 0°C ≤ T ≤ 25°C,   0.2C (200mA)
  • 25°C < T ≤ 50°C, 0.5C (500mA) recommended
Standard Discharge
  • CC
  • Current: 0.2C (200mA)
  • End of Voltage: 1.0V
Pulse Discharge current
  • ≤ 3.0A (SOC 80%), 5 sec, 25°C±2°C max.
Continuous Discharge Current
  • -20°C < T ≤ 5°C, 0.2C (200mA)  max.
  •   5°C <T ≤ 60°C, 1.0C(1000mA)  max.
Cycle Life (25°C±2°C, 0.5C Charge/1C Discharge)
  • ≥ 80% Capacity after 500 cycles
Temperature Charge: 0 to +45ºC
Discharge: -20 to +60ºC
Storage:

  • 1 day: -40ºC
  • 1 month: -20 to + 60ºC
  • 3 month: -20 to + 45ºC
  • 12 month: -20 to + 20ºC
Dimension (DxH) 10.2mm(0.40″) x44mm(1.73   “)   * tolerance ±0.2mm
Weight 13.0g (0.46 Oz)                    * tolerance±2g
Remarsk AAA battery can be made from flat top and sharp top. Here is the flat top, which is very popular as industrial battery pack.
